2026 Naivmow Terranox CM240M1 Basic

Navimow - Terranox CM240M1

Navimow Terranox is engineered for large-scale commercial lawn care. It delivers intelligent, efficient, and eco-friendly mowing performance designed to reduce labor, lower operating costs, and maintain consistent turf quality across demanding environments.

·  Overall Dimensions

• Maximum Mowing Area
• 6 acres
• Time To Mow Maximum Mowing Area*
• 72 Hours
• Dimensions
• 33.5 × 24.0 × 13.8 in
• Net Weight
• 66.02 lbs
• Key Features
• Locating System
• EFLS™ NRTK (NRTK + 360° Vision + VIO)
• Object Detection System
• VisionFence™ (360° RGB Camera + ToF)
• Driving Engine
• 4WD with dual independent steering motors
• Noise Level
• 68 dB(A)
• Protection Level
• IP66
• Weather Adaptive
• Weather Forecast + Rain Sensor
• Maximum Slope Ability
• 84% (40°)
• Antenna Installation Required
• N
• Auto-Mapping
• Y
• Auto-Recharge
• Y
• Vertical Passing Ability
• 2.8 in (5.9 in for gentle slopes)
• Multi-Zone Management
• 120
• GeoSketch™
• Y
• Signal Enhancement Antenna Supported
• Y
• Efficiency
• Battery Capacity
• 25 Ah/540 Wh
• Charging Time
• 180 min
• Full Charge Mowing Time
• 180 min
• Mowing Area per Charge
• 0.50 acre
• Cutting System
• Cutting Height
• 0.75–4 in
• Cutting Height Adjustment Method
• Auto
• Cutting Width
• 17 in
• Floating Cut System
• Y
• Anti-Clogging Cutting Disc
• Y
• Cutting Disc
• 2 Discs, 12 Blades
• Security & Safety
• GPS Tracking
• Y
• Out-of-Boundary Alarm
• Y
• Lifted Alarm
• Y
• Proximity Unlock
• Y
• PIN Code
• Y
• Object Recognition
• 200+
• Warranty
• Device & Charging Station
• 2 Years
• Battery
• 1 Year
• Others
• Connectivity
• Bluetooth & Wi-Fi & Cellular
• NRTK & Connect+（Cellular Connection）
• 2 Years Free
  Renewable Annually at $59.90
• Screen Display
• 3.5-in Colour LCD Screen
• OTA Updates - Y
